GYJK-51-60/33(16)
WINSAFE
1、 Without hydraulic hose, single hose single connector.
2、 Connector: Axis of flat, single connector, switch tools with pressure.
3、 Plastic anti-slip switch control, no sticking or sticking, make the operation more accurate.
4、 An integrated LED lighting system is provided at the handlebar to provide permanent lighting for rescuers.
5、 360 ° rotating manipulator design for multi-angle cutting operation, easy to operate.
6、 The flat design of the center bolt can enter a narrower space for cutting rescue operations.
7、 Adopts a two-way hydraulic lock inside, which has a self-locking and pressure-holding function after the tool is released.
8、 The cutting edges are designed with double blades, no sound and splashing during cutting. Ensure the safety of users.
9、 It has the advantages of light weight, flexible performance, strong functionality, labor saving, and easy operation.
Rated Working Pressure | 72MPa(720bar) |
Spreading Distance | 375mm |
Spreading Force | 51-60kN |
Cutting Capacity | 16mm(steel plate)/ф33mm(round steel) |
Pulling Distance | 245mm |
Pulling Force | 44-60kN |
Opening/closing time without load | 8-10s |
Weight | 15kg |
Size | 780×230×230mm |
